CNC Stone Cutting Machine with Precision Cutting Head Heavy-Duty Structure and High Speed Cutting for Large-Scale Stone Processing

1
MOQ
To Be Negotiable
가격
CNC Stone Cutting Machine with Precision Cutting Head Heavy-Duty Structure and High Speed Cutting for Large-Scale Stone Processing
풍모 갤러리 제품 설명 따옴표를 요구하십시오
풍모
제품 사양
모델: BLMM-1800MAX-A/B
블레이드 직경 범위: 400-700mm
절단면: 평면/호
상태: 새로운
보증: 1 년
최대 절단 길이: 3000mm
전압: 220V/380V/사용자 정의
운송 패키지: 20 피트 컨테이너 내에 로딩하세요
강조하다:

CNC Stone Cutting Machine

,

Heavy Duty CNC Stone Cutting Machine

,

High Speed CNC Stone Cutting Machine
기본 정보
원래 장소: Jinjiang, 후지안, 중국
브랜드 이름: Xianda Machinery
인증: API, CCC, SONCAP, GOST, ISO, CE, SGS;IAF
모델 번호: BLMM-1800MAX-A/B
결제 및 배송 조건
포장 세부 사항: 와이어 로프 매질, 바다/육지/철도/항공 운송에 적합합니다.
배달 시간: 15 일
지불 조건: L/C, D/A, D/P, T/T, Western Union, MoneyGram
공급 능력: 1000 세트/년
제품 설명

Dual Beam Bridge Type Linear Cutting and Milling Machine

Product Overview

Introducing the BLMM-1800MAX-A/B, a state-of-the-art dual beam bridge type linear cutting and milling machine designed for precision stone processing. This advanced CNC system features a robust bridge double beam heavy structure that combines the accuracy of linear guide rails with the power of profiling machines, making it ideal for large-scale special-shaped stone processing applications.
Product Specifications
Attribute Value
Keyword Stone Cutting Machine, Heavy-Duty Bridge Double Beam Structure
Cutting Ability High Speed
Voltage 380V
Control system CNC
Usage Roughcutting, Fine Cutting, Fine Miling and Other Functions
Application Processing of Large-sized Special-shaped Stone Materials
Warranty One Year
After-sales service provided Online support, Video technical support, Field maintenance and repair service, Field installation

Technical Specifications

Parameter Unit BLMM-1800 BLMM-1800MAX-A BLMM-1800MAX-B BLMM-1800MAX-2D-A BLMM-1800MAX-2D-B
Blade diameter mm 350-600 400-700 400-700 400-700 400-700
Max lifting travel of cutting frame mm 450 600 600 600 600
Worktable Size mm 1800*3500 1800*3500 1800*3500 1800*3500*2 1800*3500*2
Max processing length mm 3500 3500 3500 3500 3500
Main motor kw 15/18.5(Optional) 18.5/22(Optional) 18.5/22(Optional) 18.5*2/22*2(Optional) 18.5*2/22*2(Optional)
Gross motor kw 21/24.5(Optional) 24/27.5(Optional) 24/27.5(Optional) 46/53 46.5/53.5
Outline dimension mm 5300*3950*2550 6500*4350*3600 6200*4100*3600 6500*6450*3600 6200*6200*3600
Water Consumption m³/h 6 6 6 12 12

CNC Stone Cutting Machine with Precision Cutting Head Heavy-Duty Structure and High Speed Cutting for Large-Scale Stone Processing 0

CNC Stone Cutting Machine with Precision Cutting Head Heavy-Duty Structure and High Speed Cutting for Large-Scale Stone Processing 1

CNC Stone Cutting Machine with Precision Cutting Head Heavy-Duty Structure and High Speed Cutting for Large-Scale Stone Processing 2

CNC Stone Cutting Machine with Precision Cutting Head Heavy-Duty Structure and High Speed Cutting for Large-Scale Stone Processing 3

CNC Stone Cutting Machine with Precision Cutting Head Heavy-Duty Structure and High Speed Cutting for Large-Scale Stone Processing 4

CNC Stone Cutting Machine with Precision Cutting Head Heavy-Duty Structure and High Speed Cutting for Large-Scale Stone Processing 5

Equipment Features

Advanced CNC Control System

  • Three-Axis CNC System Control: Precision control of X, Y, and Z axes for complex cutting operations
  • Intelligent Programming: User-friendly interface with multiple cutting functions
  • Automated Operation: Reduces manual intervention and increases productivity
  • Real-Time Monitoring: Continuous system status feedback and error detection
  • Program Storage: Multiple program storage for different stone processing requirements

Robust Bridge Double Beam Heavy Structure

  • Dual Beam Design: Enhanced stability and rigidity for heavy-duty operations
  • Bridge Type Configuration: Optimal weight distribution and vibration dampening
  • Thermal Stability: Minimal thermal deformation during extended operations
  • Long Service Life: Durable construction ensures years of reliable performance

Precision Cutting Head Lifting Structure

  • Four Guide Column + Sleeve Copper Design: Superior stability and precision
  • Smooth Lifting Motion: Minimized vibration during vertical movement
  • High Precision Positioning: ±0.1mm positioning accuracy
  • Extended Stroke Range: Maximum vertical travel for deep cutting applications
  • Wear-Resistant Components: Copper sleeves ensure long-term precision


Frequently Asked Questions

Q: What makes this machine different from standard bridge saws?

A: The BLMM-1800MAX combines cutting and milling functions in one machine, features a dual-beam structure for enhanced stability, and offers three-axis CNC control for complex shape processing that traditional bridge saws cannot achieve.

Q: What training is required for operators?

A: We provide comprehensive training including CNC programming, machine operation, maintenance procedures, and safety protocols. Most operators become proficient within 1-2 weeks.

Q: Can this machine process all types of stone?

A: Yes, the BLMM-1800MAX is designed to handle granite, marble, quartz, microcrystalline stone, limestone, sandstone, and artificial stone materials.

Contact Information

Ready to transform your stone processing operations?
